QStyle Class

 ./myapplication -style windows

 void MyWidget::paintEvent(QPaintEvent * /* event */)
 {
     QPainter painter(this);

     QStyleOptionFocusRect option;
     option.initFrom(this);
     option.backgroundColor = palette().color(QPalette::Background);

     style()->drawPrimitive(QStyle::PE_FrameFocusRect, &option, &painter, this);
 }

     QStylePainter painter(this);
     ...
     painter.drawPrimitive(QStyle::PE_FrameFocusRect, option);

     QPainter painter(this);
     ...
     style()->drawPrimitive(QStyle::PE_FrameFocusRect, &option, &painter, this);

 class CustomStyle : public QProxyStyle
 {
     Q_OBJECT

 public:
     CustomStyle(const QWidget *widget);
     ~CustomStyle() {}

     void drawPrimitive(PrimitiveElement element, const QStyleOption *option,
                        QPainter *painter, const QWidget *widget) const override;
 };

 void CustomStyle::drawPrimitive(PrimitiveElement element, const QStyleOption *option,
                                 QPainter *painter, const QWidget *widget) const
 {
     if (element == PE_IndicatorSpinUp || element == PE_IndicatorSpinDown) {
         QPolygon points(3);
         int x = option->rect.x();
         int y = option->rect.y();
         int w = option->rect.width() / 2;
         int h = option->rect.height() / 2;
         x += (option->rect.width() - w) / 2;
         y += (option->rect.height() - h) / 2;

         if (element == PE_IndicatorSpinUp) {
             points[0] = QPoint(x, y + h);
             points[1] = QPoint(x + w, y + h);
             points[2] = QPoint(x + w / 2, y);
         } else { // PE_SpinBoxDown
             points[0] = QPoint(x, y);
             points[1] = QPoint(x + w, y);
             points[2] = QPoint(x + w / 2, y + h);
         }

         if (option->state & State_Enabled) {
             painter->setPen(option->palette.mid().color());
             painter->setBrush(option->palette.buttonText());
         } else {
             painter->setPen(option->palette.buttonText().color());
             painter->setBrush(option->palette.mid());
         }
         painter->drawPolygon(points);
     } else {
         QProxyStyle::drawPrimitive(element, option, painter, widget);
     }
 }

     const QSpinBox *spinBox = qobject_cast<const QSpinBox *>(widget);
     if (spinBox) {
     ...
     }

 #include <QtWidgets>

 #include "customstyle.h"

 int main(int argc, char *argv[])
 {
     QApplication::setStyle(new CustomStyle);
     QApplication app(argc, argv);
     QSpinBox spinBox;
     spinBox.show();
     return app.exec();
 }

 ./myapplication -style custom

     switch (element) {
         case (PE_PanelItemViewItem): {
             painter->save();

             QPoint topLeft = option->rect.topLeft();
             QPoint bottomRight = option->rect.topRight();
             QLinearGradient backgroundGradient(topLeft, bottomRight);
             backgroundGradient.setColorAt(0.0, QColor(Qt::yellow).lighter(190));
             backgroundGradient.setColorAt(1.0, Qt::white);
             painter->fillRect(option->rect, QBrush(backgroundGradient));

             painter->restore();
         break;
         }
         default:
             QProxyStyle::drawPrimitive(element, option, painter, widget);
     }

Member Function Documentation

QStyle::QStyle()

Constructs a style object.

[virtual noexcept] QStyle::~QStyle()

Destroys the style object.

[static] QRect QStyle::alignedRect(Qt::LayoutDirection direction, Qt::Alignment alignment, const QSize &size, const QRect &rectangle)

Returns a new rectangle of the specified size that is aligned to the given rectangle according to the specified alignment and direction.

int QStyle::combinedLayoutSpacing(QSizePolicy::ControlTypes controls1, QSizePolicy::ControlTypes controls2, Qt::Orientation orientation, QStyleOption *option = nullptr, QWidget *widget = nullptr) const

Returns the spacing that should be used between controls1 and controls2 in a layout. orientation specifies whether the controls are laid out side by side or stacked vertically. The option parameter can be used to pass extra information about the parent widget. The widget parameter is optional and can also be used if option is nullptr.

controls1 and controls2 are OR-combination of zero or more control types.

This function is called by the layout system. It is used only if PM_LayoutHorizontalSpacing or PM_LayoutVerticalSpacing returns a negative value.

See also layoutSpacing().

[pure virtual] void QStyle::drawComplexControl(QStyle::ComplexControl control, const QStyleOptionComplex *option, QPainter *painter, const QWidget *widget = nullptr) const

Draws the given control using the provided painter with the style options specified by option.

The widget argument is optional and can be used as aid in drawing the control.

The option parameter is a pointer to a QStyleOptionComplex object that can be cast to the correct subclass using the qstyleoption_cast() function. Note that the rect member of the specified option must be in logical coordinates. Reimplementations of this function should use visualRect() to change the logical coordinates into screen coordinates before calling the drawPrimitive() or drawControl() function.

The table below is listing the complex control elements and their associated style option subclass. The style options contain all the parameters required to draw the controls, including QStyleOption::state which holds the style flags that are used when drawing. The table also describes which flags that are set when casting the given option to the appropriate subclass.

See also drawPrimitive() and drawControl().

[pure virtual] void QStyle::drawControl(QStyle::ControlElement element, const QStyleOption *option, QPainter *painter, const QWidget *widget = nullptr) const

Draws the given element with the provided painter with the style options specified by option.

The widget argument is optional and can be used as aid in drawing the control. The option parameter is a pointer to a QStyleOption object that can be cast to the correct subclass using the qstyleoption_cast() function.

The table below is listing the control elements and their associated style option subclass. The style options contain all the parameters required to draw the controls, including QStyleOption::state which holds the style flags that are used when drawing. The table also describes which flags that are set when casting the given option to the appropriate subclass.

Note that if a control element is not listed here, it is because it uses a plain QStyleOption object.

See also drawPrimitive() and drawComplexControl().

[virtual] void QStyle::drawItemPixmap(QPainter *painter, const QRect &rectangle, int alignment, const QPixmap &pixmap) const

Draws the given pixmap in the specified rectangle, according to the specified alignment, using the provided painter.

See also drawItemText().

[virtual] void QStyle::drawItemText(QPainter *painter, const QRect &rectangle, int alignment, const QPalette &palette, bool enabled, const QString &text, QPalette::ColorRole textRole = QPalette::NoRole) const

Draws the given text in the specified rectangle using the provided painter and palette.

The text is drawn using the painter's pen, and aligned and wrapped according to the specified alignment. If an explicit textRole is specified, the text is drawn using the palette's color for the given role. The enabled parameter indicates whether or not the item is enabled; when reimplementing this function, the enabled parameter should influence how the item is drawn.

See also Qt::Alignment and drawItemPixmap().

[pure virtual] void QStyle::drawPrimitive(QStyle::PrimitiveElement element, const QStyleOption *option, QPainter *painter, const QWidget *widget = nullptr) const

Draws the given primitive element with the provided painter using the style options specified by option.

The widget argument is optional and may contain a widget that may aid in drawing the primitive element.

The table below is listing the primitive elements and their associated style option subclasses. The style options contain all the parameters required to draw the elements, including QStyleOption::state which holds the style flags that are used when drawing. The table also describes which flags that are set when casting the given option to the appropriate subclass.

Note that if a primitive element is not listed here, it is because it uses a plain QStyleOption object.

See also drawComplexControl() and drawControl().

[pure virtual] QPixmap QStyle::generatedIconPixmap(QIcon::Mode iconMode, const QPixmap &pixmap, const QStyleOption *option) const

Returns a copy of the given pixmap, styled to conform to the specified iconMode and taking into account the palette specified by option.

The option parameter can pass extra information, but it must contain a palette.

Note that not all pixmaps will conform, in which case the returned pixmap is a plain copy.

See also QIcon.

[pure virtual] QStyle::SubControl QStyle::hitTestComplexControl(QStyle::ComplexControl control, const QStyleOptionComplex *option, const QPoint &position, const QWidget *widget = nullptr) const

Returns the sub control at the given position in the given complex control (with the style options specified by option).

Note that the position is expressed in screen coordinates.

The option argument is a pointer to a QStyleOptionComplex object (or one of its subclasses). The object can be cast to the appropriate type using the qstyleoption_cast() function. See drawComplexControl() for details. The widget argument is optional and can contain additional information for the function.

See also drawComplexControl() and subControlRect().

[virtual] QRect QStyle::itemPixmapRect(const QRect &rectangle, int alignment, const QPixmap &pixmap) const

Returns the area within the given rectangle in which to draw the specified pixmap according to the defined alignment.

[virtual] QRect QStyle::itemTextRect(const QFontMetrics &metrics, const QRect &rectangle, int alignment, bool enabled, const QString &text) const

Returns the area within the given rectangle in which to draw the provided text according to the specified font metrics and alignment. The enabled parameter indicates whether or not the associated item is enabled.

If the given rectangle is larger than the area needed to render the text, the rectangle that is returned will be offset within rectangle according to the specified alignment. For example, if alignment is Qt::AlignCenter, the returned rectangle will be centered within rectangle. If the given rectangle is smaller than the area needed, the returned rectangle will be the smallest rectangle large enough to render the text.

See also Qt::Alignment.

[pure virtual] int QStyle::layoutSpacing(QSizePolicy::ControlType control1, QSizePolicy::ControlType control2, Qt::Orientation orientation, const QStyleOption *option = nullptr, const QWidget *widget = nullptr) const

Returns the spacing that should be used between control1 and control2 in a layout. orientation specifies whether the controls are laid out side by side or stacked vertically. The option parameter can be used to pass extra information about the parent widget. The widget parameter is optional and can also be used if option is nullptr.

This function is called by the layout system. It is used only if PM_LayoutHorizontalSpacing or PM_LayoutVerticalSpacing returns a negative value.

See also combinedLayoutSpacing().

[since 6.1] QString QStyle::name() const

Returns the name of the style.

This value can be used to create a style with QStyleFactory::create().

This function was introduced in Qt 6.1.

See also QStyleFactory::create().

[pure virtual] int QStyle::pixelMetric(QStyle::PixelMetric metric, const QStyleOption *option = nullptr, const QWidget *widget = nullptr) const

Returns the value of the given pixel metric.

The specified option and widget can be used for calculating the metric. The option can be cast to the appropriate type using the qstyleoption_cast() function. Note that the option may be zero even for PixelMetrics that can make use of it. See the table below for the appropriate option casts:

Some pixel metrics are called from widgets and some are only called internally by the style. If the metric is not called by a widget, it is the discretion of the style author to make use of it. For some styles, this may not be appropriate.

[virtual] void QStyle::polish(QWidget *widget)

Initializes the appearance of the given widget.

This function is called for every widget at some point after it has been fully created but just before it is shown for the very first time.

Note that the default implementation does nothing. Reasonable actions in this function might be to call the QWidget::setBackgroundMode() function for the widget. Do not use the function to set, for example, the geometry. Reimplementing this function provides a back-door through which the appearance of a widget can be changed, but with Qt's style engine it is rarely necessary to implement this function; reimplement drawItemPixmap(), drawItemText(), drawPrimitive(), etc. instead.

The QWidget::inherits() function may provide enough information to allow class-specific customizations. But because new QStyle subclasses are expected to work reasonably with all current and future widgets, limited use of hard-coded customization is recommended.

See also unpolish().

[virtual] void QStyle::polish(QApplication *application)

This is an overloaded function.

Late initialization of the given application object.

[virtual] void QStyle::polish(QPalette &palette)

This is an overloaded function.

Changes the palette according to style specific requirements for color palettes (if any).

See also QPalette and QApplication::setPalette().

const QStyle *QStyle::proxy() const

This function returns the current proxy for this style. By default most styles will return themselves. However when a proxy style is in use, it will allow the style to call back into its proxy.

[pure virtual] QSize QStyle::sizeFromContents(QStyle::ContentsType type, const QStyleOption *option, const QSize &contentsSize, const QWidget *widget = nullptr) const

Returns the size of the element described by the specified option and type, based on the provided contentsSize.

The option argument is a pointer to a QStyleOption or one of its subclasses. The option can be cast to the appropriate type using the qstyleoption_cast() function. The widget is an optional argument and can contain extra information used for calculating the size.

See the table below for the appropriate option casts:

See also ContentsType and QStyleOption.

[static] int QStyle::sliderPositionFromValue(int min, int max, int logicalValue, int span, bool upsideDown = false)

Converts the given logicalValue to a pixel position. The min parameter maps to 0, max maps to span and other values are distributed evenly in-between.

This function can handle the entire integer range without overflow, providing that span is less than 4096.

By default, this function assumes that the maximum value is on the right for horizontal items and on the bottom for vertical items. Set the upsideDown parameter to true to reverse this behavior.

See also sliderValueFromPosition().

[static] int QStyle::sliderValueFromPosition(int min, int max, int position, int span, bool upsideDown = false)

Converts the given pixel position to a logical value. 0 maps to the min parameter, span maps to max and other values are distributed evenly in-between.

This function can handle the entire integer range without overflow.

By default, this function assumes that the maximum value is on the right for horizontal items and on the bottom for vertical items. Set the upsideDown parameter to true to reverse this behavior.

See also sliderPositionFromValue().

[pure virtual] QIcon QStyle::standardIcon(QStyle::StandardPixmap standardIcon, const QStyleOption *option = nullptr, const QWidget *widget = nullptr) const

Returns an icon for the given standardIcon.

The standardIcon is a standard pixmap which can follow some existing GUI style or guideline. The option argument can be used to pass extra information required when defining the appropriate icon. The widget argument is optional and can also be used to aid the determination of the icon.

[virtual] QPalette QStyle::standardPalette() const

Returns the style's standard palette.

Note that on systems that support system colors, the style's standard palette is not used. In particular, the Windows Vista and Mac styles do not use the standard palette, but make use of native theme engines. With these styles, you should not set the palette with QApplication::setPalette().

See also QApplication::setPalette().

[pure virtual] int QStyle::styleHint(QStyle::StyleHint hint, const QStyleOption *option = nullptr, const QWidget *widget = nullptr, QStyleHintReturn *returnData = nullptr) const

Returns an integer representing the specified style hint for the given widget described by the provided style option.

returnData is used when the querying widget needs more detailed data than the integer that styleHint() returns. See the QStyleHintReturn class description for details.

[pure virtual] QRect QStyle::subControlRect(QStyle::ComplexControl control, const QStyleOptionComplex *option, QStyle::SubControl subControl, const QWidget *widget = nullptr) const

Returns the rectangle containing the specified subControl of the given complex control (with the style specified by option). The rectangle is defined in screen coordinates.

The option argument is a pointer to QStyleOptionComplex or one of its subclasses, and can be cast to the appropriate type using the qstyleoption_cast() function. See drawComplexControl() for details. The widget is optional and can contain additional information for the function.

See also drawComplexControl().

[pure virtual] QRect QStyle::subElementRect(QStyle::SubElement element, const QStyleOption *option, const QWidget *widget = nullptr) const

Returns the sub-area for the given element as described in the provided style option. The returned rectangle is defined in screen coordinates.

The widget argument is optional and can be used to aid determining the area. The QStyleOption object can be cast to the appropriate type using the qstyleoption_cast() function. See the table below for the appropriate option casts:

[virtual] void QStyle::unpolish(QWidget *widget)

Uninitialize the given widget's appearance.

This function is the counterpart to polish(). It is called for every polished widget whenever the style is dynamically changed; the former style has to unpolish its settings before the new style can polish them again.

Note that unpolish() will only be called if the widget is destroyed. This can cause problems in some cases, e.g, if you remove a widget from the UI, cache it, and then reinsert it after the style has changed; some of Qt's classes cache their widgets.

See also polish().

[virtual] void QStyle::unpolish(QApplication *application)

This is an overloaded function.

Uninitialize the given application.

[static] Qt::Alignment QStyle::visualAlignment(Qt::LayoutDirection direction, Qt::Alignment alignment)

Transforms an alignment of Qt::AlignLeft or Qt::AlignRight without Qt::AlignAbsolute into Qt::AlignLeft or Qt::AlignRight with Qt::AlignAbsolute according to the layout direction. The other alignment flags are left untouched.

If no horizontal alignment was specified, the function returns the default alignment for the given layout direction.

QWidget::layoutDirection

[static] QPoint QStyle::visualPos(Qt::LayoutDirection direction, const QRect &boundingRectangle, const QPoint &logicalPosition)

Returns the given logicalPosition converted to screen coordinates based on the specified direction. The boundingRectangle is used when performing the translation.

See also QWidget::layoutDirection.

[static] QRect QStyle::visualRect(Qt::LayoutDirection direction, const QRect &boundingRectangle, const QRect &logicalRectangle)

Returns the given logicalRectangle converted to screen coordinates based on the specified direction. The boundingRectangle is used when performing the translation.

This function is provided to support right-to-left desktops, and is typically used in implementations of the subControlRect() function.

See also QWidget::layoutDirection.
